Earth-Track Hoes
Excavator Kubota KX018-4
 Image for reference only | |
Manufacturer Link: <Click Here>
Model: KX018-4
Additional Information
- Model: KX018-4
- Type of tracks: Rubber
- Engine
- Model: Kubota D902-BH-E4
- Output (SAE J1995 gross) HP (kW)/rpm: 16.1 (12.0) / 2300
- Output (SAE J1349 net) HP (kW)/rpm: 15.5 (11.6) / 2300
- Displacement cu. in. (cc): 5.80 (898)
- Dimensions
- Overall length - 12'2.1"
- Overall height - 7'7.7"
- Overall width - 4'3.2"
- Min. ground clearance - 6.3"
- Hydraulic system
- Pump capacity GPM (l/min): 4.6 (17.3) x 2 / 2.8 (10.4) x 1 / 1.7 (6.2) x1
- Auxiliary hydraulic flow GPM (l/min): 7.4 (27.7)
- Max. breakout force: Bucket / Arm - 3594 lbs / 1852 lbs
- Drive system
- Travel speed Low / High - 1.4 mph / 2.5 mph
- Max. traction force - 4542 lbs
- Tumbler distance - 4'1"
- Crawler length: - 5'2.6"
- Shoe width: - 9.1"
- Ground contact pressure - 3.7 psi
- Swing system
- Unit swing speed - 9.1 rpm
- Boom swing angle Left / Right degree: 75 / 60
- Blade Dimensions
- Width - 4'3.2" / 3'3.0"
- Height - 9.1"
- Max. lift above ground - 9.1"
- Max. drop below ground - 9.1"
- Hydraulic oil (reservoir / system) gal (l): 4.1
- Fuel reservoir gal- 5.6
- Operating weight (Including operator’s weight 175 lbs)- 3748 lbs
* Prices are subject to change. Delivery and other applicable fees are not included in this price estimate.
Please call us for any questions on our excavator kubota kx018 4 rentals in Baker City, Island City, Pendleton OR, and Pasco WA, serving Eastern Oregon
