Earth-Track Hoes
Excavator Kobelco SK160LC
 Image for reference only | |
Model: SK160LC
Additional Information
- Fish Oil
- Length: 28 ft. 5 in. (8.65 m)
- Height: To Top of Boom: 9 ft. 9 in. (2.96 m)
- To Top of Cab: 9 ft. 8 in. (2.95 m)
- Width: With 800 mm Shoe: 8 ft. 6 in. (2.59 m)
- Weight: 36,800 lbs. (16,700 kg)
- Ground Clearance: Rear End: 3 ft. 5 in. (1.03 m)
- Undercarriage: 18.9 in. (480 mm)
- Fuel Tank Capacity: 74.2 gal. (281 l)
- Hydraulic Tank Capacity: 42 gal. (159 l)
- Track Width: 23.6 in. (600 mm)
- Engine Make: Mitsubishi
- Engine Model: 4D34-TEG
- Fuel Type: Diesel
- Bore x Stroke: 4.09 x 4.53 in. (104 x 115 mm)
- Net Horsepower: 112 hp (82 kW)
- Cooling: Water-cooled
- Displacement: 238 ci (3.907 l)
- Rated Speed: 3.7 mph (6.0 km/h)
- Reserve Capacity: 37.8 gal. (143 l)
- Travel Speed - Forward: 2.5 mph (4.0 km/h)
- Arm Length: 10 ft. 2 in. (3.1 m)
- Dig Depth: 21 ft. 7 in. (6.57 m)
- Bucket Digging Force:
- SAE: 24,900 lbs. (11,300 kg)
- ISO: 28,000 lbs. (12,700 kg)
- Dump Height:
- Maximum: 22 ft. 10 in. (6.96 m)
- Minimum: 6 ft. 9 in. (2.07 m)
Consider these items to go with your rental:
* Prices are subject to change. Delivery and other applicable fees are not included in this price estimate.
Please call us for any questions on our excavator kobelco sk160lc rentals in Baker City, Island City, Pendleton OR, and Pasco WA, serving Eastern Oregon
