Compressors
Compressor 185 CFM DSL CP KD
 Image for reference only | |
Manufacturer Link: <Click Here>
Model: CPS 185 KD T4F
Additional Information
- Chicago Pneumatic's CPS 185 KD T4F portable diesel compressor is built to deliver reliable performance and flexibility for a wide range of general construction
- applications. It’s quiet and easy to use, thanks to a proven 4-cylinder, naturally aspirated Kubota engine, a noisereducing enclosure and straightforward controls.
- USER-FRIENDLY
- CONTROLS
- CP's new intuitive controller makes the transition to Final Tier 4 easy. It takes the guesswork out of operation and provides a long list of diagnostics and protective shutdowns.
- LOW-MAINTENANCE DESIGN
- Few moving parts minimize mechanical wear. In addition, the durable galvanneal sheet metal enclosure with powdercoat paint helps reduce noise and corrosion.
- CONVENIENT TRANSPORT
- The towable design has an adjustable-height hitch, jack stand and safety chains, as well as recessed towing lights and torsion bar suspension.
- Specifications
- Compressor
- Actual Free Air Delivery cfm: 185**
- Normal Effective Working Pressure psi: 100
- Maximum Unloading Working Pressure psi: 125
- Working Pressure Range psi: 58-125
- Discharge Outlet Quantity: 2 x 3/4"
- Engine
- Engine Model: Kubota V2403
- Number of Cylinders: 4
- US EPA Emissions: Tier 4 Final
- Cooling System: Water (PAR Cool)
- Engine Power hp: 49
- Displacement in3 (l): 147 (2.4)
- Rated Speed (high): 2,700 rpm
- Rated Speed (low): 1,600 rpm
- Fuel Consumption gal/hr (l/hr) @ 100% load: 2.3 (8.7)
- Fuel Tank Capacity gal (l): 20 (75)
- Sound Pressure Level dBa @ 23' (7m) @ 75% load: 76
- Dimensions & Weight
- Overall Length in (m) 131 (3.33)
- Overall Width in (m) 60 (1.5)
- Overall Height in (m) 55.25 (1.4)
- Weight Wet lb (kg) 2,400 (1,089)
- ** According to ISO1217 ed.3 1998 annex D. Subject to change without prior notice.
