Earth-Track Hoes
Excavator Kubota K008-3
 Image for reference only | |
Manufacturer Link: <Click Here>
Model: K008-3
Additional Information
- Model: K008-3
- Type of tracks: Rubber
- Operating Weight: 2200 lbs
- Engine
- SAE J1995 Gross: 10.3HP / 2050 rpm
- SAE J1349 Net: 10.1HP / 2050 rpm
- Displacement: 44.0 in³
- Digging Depth: 5'8"
- Dimensions
- Overall length - 9'0"
- Overall height - 7'4"
- Overall width - 2'10" / 2'4"
- Hydraulic system
- Pump capacity - GPM: 5.55
- Auxiliary hydraulic flow - GPM: 5.55
- Max. breakout force
- Bucket - 2200lbs
- Arm - 1010lbs
- Min. ground clearance - 5.9"
- Drive system
- Travel speed - 1.2 / 2.5 mph
- Max. traction force - 1695 lbs
- Tumbler distance - 2'11"
- Crawler length - 4'0"
- Shoe width - 7.1"
- Ground contact pressure - 3.55 psi
- Swing system
- Unit swing speed - 8.3 rpm
- Boom swing angle
- Left - 55 degrees
- Right 60 degrees
- Blade
- Dimensions - Width 2'4" / 2'10"
- Height - 7.9"
- Max. lift above ground - 7.9"
- Max. drop below ground - 7.1"
- Working Range
- Max. digging height - 9'5"
- Max. dumping height - 6'8"
- Max. digging depth - 5'8"
- Max. vertical digging depth - 4'6"
- Max. digging radius @ ground - 9'11"
- Max. digging radius - 10'1"
- Min. turning radius:
- Without swing: 3'8"
- With swing: 3'2"
- Min. tail turning radius - 2'6"
- 7152726
- Hydraulic oil - GPM 3.30 / 4.49
- Fuel reservoir - GPM: 3.17
- Operating weight (Including operator’s weight 175 lbs.) - 220 lbs
* Prices are subject to change. Delivery and other applicable fees are not included in this price estimate.
