Aerial Boom Lifts
Work Platform Genie S60-X 4WD
 Image for reference only | |
Manufacturer Link: <Click Here>
Model: S-60
Additional Information
- Measurements:
- Height, working maximum 66 ft / 20.3 m
- Height, platform maximum 60 ft / 18.3 m
- Height, stowed maximum 8 ft 11 in / 2.72 m
- Horizontal reach maximum: 50 ft 10 in / 15.5 m
- Width: 8 ft 2 in / 2.49 m
- Length, stowed: 27 ft 11 in / 8.5 m
- Maximum load capacity: 500 lb / 227 kg
- Maximum load capacity: 1000 lb / 340 kg
- (with proper counterweight configuration)
- Maximum wind speed: 28 mph / 12.5 m/s
- Wheelbase: 8 ft 2 in / 2.5 m
- Turning radius (outside): 18 ft 2 in / 5.5 m
- Turning radius (inside): 7 ft 9 in / 2.4 m
- Turntable rotation (degrees): continuous
- Turntable tailswing: 4 ft / 1.22 m
- Drive speeds:
- Drive speed, stowed, 4WD: 3.0 mph / 4.8 km/h
- Drive speed, raised or extended: 0.7 mph / 1.1 km/h
- Ground clearance, center: 14 in / 37 cm
- Ground clearance, axle: 13 in / 33 cm
- Controls: 12V DC proportional
- Weight: 20,825 lbs
- Platform:
- Platform dimensions: 72 in x 30 in / 1.8 m x 76 cm
- 6 foot (length x width)
- Platform dimensions: 96 in x 36 in / 2.4 m x 91 cm
- 8 foot (length x width)
- Platform leveling: self-leveling
- Platform rotation: 160°
- AC outlet in platform: standard
- Hydraulic pressure, maximum: 3000 psi / 207 bar
- (Boom functions)
- System voltage: 12V
- Tire size: 355/55D 625
- High flotation tire size 41/18LL x 22.5, 14 ply
- Maximum slope rating, stowed position, 4WD
- Platform downhill: 45% / 24°
- Platform uphill: 30% / 17°
- Side slope: 25% / 14°
- Note: Slope rating is subject to ground conditions and adequate traction.
- Fuel tank capacity: 40 gallons / 151 liters
* Prices are subject to change. Delivery and other applicable fees are not included in this price estimate.
Please call us for any questions on our work platform genie s60 x 4wd rentals in Baker City, Island City, Pendleton OR, and Pasco WA, serving Eastern Oregon
